TCMT1104 The Kingbright TCMT1104 is a single-channel optocoupler with a phototransistor output, housed in an SSOP-4 package. It offers an isolation test voltage of 3750 V RMS.
Mfr Part #:

TCMT1104

Available from 1 distributors
Mfr Name: Kingbright
Kingbright
The Kingbright TCMT1104 is a single-channel optocoupler with a phototransistor output, housed in an SSOP-4 package. It offers an isolation test voltage of 3750 V RMS.
✓ Total Stock: 214 pcs
$ Price Range: $8.12

TCMT1104 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ACK ELEKTRONIK ✓
Non-Authorised Inventory information
214 pcs
On Request
214 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TCMT1104 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Spacing
Mounting Type
View Similar Products (0)

TCMT1104 Description

Short technical summary and product information.

The TCMT1104 series optocoupler from Kingbright features a phototransistor output optically coupled to a gallium arsenide infrared-emitting diode. This single-channel device is designed for applications requiring high safety requirements, with elements mounted on a single leadframe to maintain a fixed distance between input and output.



Key electrical specifications include an AC isolation test voltage of 3750 V RMS and a low coupling capacitance of typically 0.3 pF. The current transfer ratio (CTR) is available in selected groups, with values ranging from 50% to 600% at 5 mA forward current, depending on the specific part number.



This optocoupler is housed in a low-profile, half-pitch SSOP-4 package, suitable for surface mounting. It is available only on tape and reel. The TCMT1104 is designed for general applications, including programmable logic controllers, modems, and answering machines.



Agency approvals include UL1577, cUL, DIN EN 60747-5-5 (VDE 0884-5), FIMKO, BSI, and CQC, indicating its suitability for various international standards.

TCMT1104 Quick Information

Product Type: Optocoupler
Series: TCMT110.
Canonical Name: TCMT1104 Optocoupler, Phototransistor Output, Single Channel, Half Pitch Mini-Flat Package
Subcategory: Phototransistor Output

TCMT1104 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TCMT1104 Estimated Pricing

Qty Low High
1+ $8.12 $8.12

Estimated market price range - modelled values for guidance only, not live distributor offers.

TCMT1104 Features

  • Single channel phototransistor output optocoupler
  • 3750 V RMS AC isolation test voltage
  • Low coupling capacitance of 0.3 pF
  • SSOP-4 low profile package
  • Available on tape and reel

TCMT1104 Applications

  • Used in programmable logic controllers
  • Suitable for modem applications
  • Applied in answering machines
  • General purpose isolation needs

TCMT1104 FAQs

4 frequently asked questions generated from this part’s specifications.
What is the isolation voltage of the TCMT1104 optocoupler?

The AC isolation test voltage is 3750 V RMS.

What is the typical coupling capacitance for this optocoupler?

The typical coupling capacitance is 0.3 pF.

What package type is the TCMT1104 optocoupler available in?

It is available in an SSOP-4 package.

Does the TCMT1104 optocoupler come on tape and reel?

Yes, it is available only on tape and reel.
