TAJB226K020RNJ The Kyocera AVX TAJB226K020RNJ is a 22 µF MnO2 tantalum capacitor with a 20V dc rating. It features a surface mount package and AEC-Q200 automotive standard compliance.
Mfr Part #:

TAJB226K020RNJ

Available from 5 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
The Kyocera AVX TAJB226K020RNJ is a 22 µF MnO2 tantalum capacitor with a 20V dc rating. It features a surface mount package and AEC-Q200 automotive standard compliance.
✓ Total Stock: 18,296 pcs
$ Price Range: $1.32

TAJB226K020RNJ Available from 5 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TAJB226K020RNJ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Country of Origin
Dissipation Factor
Failure Rate
Halogen Free
Lead Style
SVHC Present
Technology
Terminal Type
Tolerance
Voltage
View Similar Products (0)

TAJB226K020RNJ Description

Short technical summary and product information.

This Kyocera AVX TAJB226K020RNJ is a high-performance MnO2 tantalum capacitor designed for general-purpose applications. It offers a capacitance of 22 µF with a voltage rating of 20V dc and a low equivalent series resistance (ESR) of 1.8Ω.



The capacitor operates within a temperature range of -55°C to 125°C and has a tolerance of ±10%. Its solid electrolyte type ensures reliability and stability.



Packaged for surface mounting, the TAJB226K020RNJ has dimensions of 3.5mm in length, 1.9mm in height, and 2.8mm in depth. It meets the AEC-Q200 automotive standard, making it suitable for demanding environments.



Key electrical characteristics include a surge voltage of 26V, a dissipation factor of 6%, and a leakage current of 4.4µA. The country of origin is El Salvador.

TAJB226K020RNJ Quick Information

Product Type: Tantalum Capacitor
Series: TAJ
Canonical Name: Kyocera AVX TAJB226K020RNJ 22 µF MnO2 Tantalum Capacitor 20V dc Surface Mount
Subcategory: Tantalum Capacitor

TAJB226K020RNJ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TAJB226K020RNJ Estimated Pricing

Qty Low High
1+ $1.32 $1.32

Estimated market price range - modelled values for guidance only, not live distributor offers.

TAJB226K020RNJ Features

  • 22 µF capacitance with 20V dc rating.
  • Low 1.8Ω equivalent series resistance.
  • Wide -55°C to 125°C operating temperature.
  • AEC-Q200 automotive standard compliant.
  • Compact 3528-21 surface mount package.

TAJB226K020RNJ Applications

  • Suitable for automotive electronic systems.
  • Used in power supply filtering.
  • Ideal for general purpose coupling.
  • Applied in industrial control circuits.
  • Fits compact electronic designs.

TAJB226K020RNJ FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance of the TAJB226K020RNJ?

The capacitance of the TAJB226K020RNJ is 22µF.

What is the voltage rating of the TAJB226K020RNJ?

The voltage rating is 20V DC.

What is the operating temperature range for the TAJB226K020RNJ?

The operating temperature range is from -55°C to 125°C.

What is the Equivalent Series Resistance (ESR) of this capacitor?

The Equivalent Series Resistance (ESR) is 1.8Ω.

What is the package type for the TAJB226K020RNJ?

The package type is 3528-21.

What is the tolerance of the TAJB226K020RNJ?

The tolerance is ±10%.

Is the TAJB226K020RNJ qualified for automotive applications?

Yes, it is AEC-Q200 qualified.
