TAH20P2R20JE
Ohmite
The Ohmite TAH20P2R20JE is a thick film resistor with a resistance of 2.2 Ohms and a power rating of 20W. It features a ±5% tolerance and is housed in a TO-220 package.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Power (Watts) | |
| Resistance | |
| Supplier Device Package | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This Ohmite TAH20P2R20J is a through-hole resistor designed for various electronic applications. It offers a resistance value of 2.2 Ohms with a tight tolerance of ±5%, ensuring accurate circuit performance. The resistor has a substantial power rating of 20W, making it suitable for applications requiring significant power dissipation.
Constructed with thick film technology, this component is built for reliability and durability. It features moisture-resistant and pulse-withstanding capabilities, enhancing its robustness in demanding environments. The temperature coefficient is ±100ppm/°C, providing stable operation across a range of temperatures.
The TAH20P2R20J comes in a TO-220 package, a common standard for power components that facilitates easy mounting and heat dissipation. Its dimensions are approximately 10.41mm in length, 3.18mm in width, and 16.52mm in height. The component has two terminations, consistent with its through-hole design.
This resistor is an excellent choice for designers needing a reliable power resistor with specific resistance and power handling capabilities. Its features make it suitable for power supply circuits, motor controls, and other applications where power dissipation and stability are critical.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.01 | $0.01 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 2.2 Ohms.
The power rating is 20W.
The tolerance is ±5%.
The temperature coefficient is ±100ppm/°C.
It is supplied in a TO-220-2 package.
