TA45-ABFGS190C0-AZM12
Schurter Inc.
The TA45-ABFGS190C0-AZM12 is a circuit breaker manufactured by Schurter Inc. with a rated voltage of 240 VAC and a current range of 0.05 to 20 A.
| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating | |
| Weight |
The Schurter Inc. TA45-ABFBP190C0-AZM11 is a thermal circuit breaker designed for reliable overload protection. This 2-pole unit offers a rated current of 19A and a voltage rating of 240 VAC, with a DC rating of 60 VDC.
Featuring a rocker actuation type and a panel mount, snap-in design, this circuit breaker is suitable for various industrial applications. It provides a conditional short circuit capacity of 1 kA at 240 VAC and meets IEC 60934 standards. The device operates within an allowable temperature range of -10 °C to 55 °C.
Key specifications include a mechanical lifetime of 50,000 switching cycles and an insulation resistance of over 100 MΩ at 500 VDC. The degree of protection is IP40 on the front side, which can be increased to IP54 with a factory-mounted protection cover. Approvals include CSA C22.2 No 235, IEC60934, GB17701, and UL1077.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The rated voltage is 240 VAC.
The current rating is 19A.
It uses a thermal tripping type.
It is a panel mount, snap-in type.
It has an ingress protection rating of IP40 on the front side and IP54 with a factory-mounted cover.
