| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
99 pcs
|
99 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector Type | |
| Contact Finish | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Ingress Protection | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Primary Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Amphenol Tuchel Industrial T 3400 002 is a 6-position circular plug connector from the C 091 series. It features male pins in a metal die-cast shell with nickel finish, terminated via solder cups for reliable soldered connections. The connector is free hanging (in-line), keyed for proper orientation, and features a threaded coupling mechanism for secure mating.
Rated for 7A current and 250V voltage, this plug is designed for industrial applications requiring a shielded connection. An integral cable clamp and strain relief provide mechanical support to the cable entry. The operating temperature range spans -40°C to 100°C, with an IP40 ingress protection rating suitable for indoor environments.
The shell size is M16-6, and contacts are finished in silver for good conductivity. The C 091 series is well-established in factory automation, measurement equipment, and other industrial systems where robust, medium-duty circular connectors are needed.
| Qty | Low | High |
|---|---|---|
| 1+ | $14.77 | $14.77 |
| 10+ | $13.81 | $13.81 |
| 20+ | $12.55 | $12.55 |
| 50+ | $12.16 | $12.16 |
| 100+ | $11.53 | $11.53 |
| 200+ | $11.22 | $11.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 6 positions (6 male pins).
It is rated for 7 A at 250 V.
Free hanging (in-line) with a threaded coupling.
The operating temperature range is -40°C to 100°C.
The connector has an IP40 rating.
Solder cup termination is used.
