| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
20 pcs
|
20 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Resistance | |
| Coil Voltage | |
| Contact Material | |
| Contact Resistance | |
| Country of Origin | |
| Failure Rate | |
| Height | |
| Length | |
| Product Type | |
| SVHC Present | |
| Terminal Type | |
| Width |
This Fujitsu SY-9W-K is a signal relay designed for through-hole mounting. It operates with a 9V DC coil and offers a Single Pole Double Throw (SPDT) contact configuration.
The relay is capable of switching up to 1A of current and can handle AC voltages up to 120V or DC voltages up to 60V. Its specifications include a switching power of 24W, a contact resistance of 100mΩ, and a coil resistance of 540Ω. The coil power consumption is 150mW.
Designed for a range of environmental conditions, the SY-9W-K has a minimum operating temperature of -30°C and a maximum operating temperature of 90°C. The physical dimensions are 12.5mm in length, 7.4mm in width, and 9.5mm in height. The terminal type is solder, facilitating easy integration into PCB designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.16 | $1.16 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The coil voltage for the Fujitsu SY-9W-K relay is 9V dc.
The SY-9W-K signal relay has an SPDT (Single Pole Double Throw) contact configuration.
The maximum switching current for this Fujitsu relay is 1A.
The SY-9W-K relay operates between -30°C and 90°C.
The SY-9W-K relay is designed for through-hole mounting.
