| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Storage Temperature | |
| Type | |
| Voltage | |
| Weight |
The TDK Corporation SWS100-5 is an enclosed AC/DC converter designed for chassis mounting. It delivers a nominal output voltage of 5VDC with a maximum current of 20A, providing a total power output of 100W. The unit accepts a universal AC input voltage range of 85-265 VAC and also supports a DC input range of 110-330 VDC.
Key electrical features include adjustable output, power factor correction (PFC), and a typical efficiency of 75%. The operating temperature range is -20°C to 74°C with derating. Safety specifications include withstand voltages of 2kVAC (Input to Ground), 3kVAC (Input to Output), and 500VAC (Output to Ground).
This converter is suitable for ITE (Commercial) applications and meets various safety agency approvals including CE, cURus, and TUV. Its dimensions are 188.0mm in length, 96.0mm in width, and 45.0mm in height, with a weight of approximately 600g. The product comes with a 2-year warranty.
The SWS100-5 has a nominal output voltage of 5VDC.
The maximum output current for the SWS100-5 is 20A.
The SWS100-5 has a power rating of 100W.
The SWS100-5 accepts a universal AC input voltage range of 85-265 VAC.
The operating temperature range for the SWS100-5 is -20°C to 74°C with derating.
The SWS100-5 measures 188.0mm in length, 96.0mm in width, and 45.0mm in height.
The SWS100-5 has safety agency approvals including CE, cURus, and TUV.
