| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
150 pcs
|
150 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Plating | |
| Contact Resistance | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The SWR204-NRTN-D03-ST-GA is a dual-row header from Sullins Connector Solutions, part of the SWR204 series. It features 6 positions arranged in 2 rows with a 2.00mm pitch and row spacing. The header is shrouded with a 4-wall design and includes a detent lock for secure mating with the SWH204 series dual-row housing.
Electrical specifications include a current rating of 3A per contact, voltage rating of 50V AC/DC, and low contact resistance of 10mΩ maximum. The insulation material is polyamide (PA66) with UL94 V-0 flammability rating, and the operating temperature range is -25°C to +85°C. Contacts are made of brass with nickel underplate and pure tin plating.
This header is designed for board-to-cable/wire applications, with through-hole mounting and solder termination. The square contacts measure 0.50mm width and 3.00mm length. The insulator dimensions are 4.00mm length, 7.90mm width, and 6.50mm height.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.29 | $0.29 |
| 10+ | $0.25 | $0.25 |
| 100+ | $0.21 | $0.21 |
| 500+ | $0.19 | $0.19 |
| 2,000+ | $0.17 | $0.17 |
| 6,000+ | $0.16 | $0.16 |
| 10,000+ | $0.15 | $0.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
This header has 6 positions, arranged in 2 rows.
The pitch is 2.00mm (0.079 inches) with 2.00mm row spacing.
The current rating is 3A per contact.
The voltage rating is 50V AC/DC.
This header is through-hole mount with solder termination.
The operating temperature range is -25°C to +85°C.
Yes, it features a detent lock fastening type.
