| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
299 pcs
|
299 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Capacitance | |
| Dissipation Factor | |
| Features | |
| Height | |
| Lead Spacing | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Voltage | |
| Width |
The Kyocera AVX SV13CC332KAR is a high voltage multilayer ceramic capacitor (MLCC) from the SV series. It offers a capacitance of 3300 pF with a rated voltage of 630V and a tolerance of ±10%. The X7R temperature coefficient provides a capacitance change of ±15% over the operating temperature range of -55°C to +125°C.
This radial leaded capacitor features a conformal epoxy coating with high insulation resistance and high dielectric strength, minimizing partial discharge and enhancing long-term reliability. The internal design reduces electric field stresses, making it suitable for demanding high voltage environments.
Typical applications include snubbers in high frequency power converters, resonators in switched-mode power supplies (SMPS), and high voltage coupling or DC blocking. The component is through-hole mounted with a lead spacing of 5.08mm and straight leads.
The SV series is designed for high voltage systems where low ESR, low leakage, and small size are critical. The part is RoHS3 compliant and has an MSL of 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 300+ | $10.98 | $10.98 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The capacitance is 3300 pF with a tolerance of ±10%.
The rated voltage is 630V DC.
The temperature coefficient is X7R, with a maximum capacitance change of ±15% over the operating temperature range.
The operating temperature range is -55°C to +125°C.
The package is radial through-hole with a lead spacing of 5.08mm (0.200").
Dissipation factor is 2.5% max at 25°C, 1kHz. Insulation resistance is 100K MΩ min at 25°C, 500V.
The part is listed as RoHS3 Compliant, but this is unverified.
