STSJ100NHS3LL The VBsemi STSJ100NHS3LL is an N-channel Power MOSFET featuring 30V drain-source voltage and 20A continuous current. It is housed in a PowerSO-8 package.
Mfr Part #:

STSJ100NHS3LL

Available from 1 distributors
Mfr Name: VBsemi
VBsemi
The VBsemi STSJ100NHS3LL is an N-channel Power MOSFET featuring 30V drain-source voltage and 20A continuous current. It is housed in a PowerSO-8 package.
✓ Total Stock: 25,868 pcs

STSJ100NHS3LL Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
25,868 pcs
On Request
25868 pcs On Request 1 On Request On Request 19+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

STSJ100NHS3LL Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Diode Type
Package / Case
SVHC Present
Storage Temperature
Technology
View Similar Products (0)

STSJ100NHS3LL Description

Short technical summary and product information.

The STSJ100NHS3LL from VBsemi is an N-channel Power MOSFET utilizing STripFET III technology. This device offers a drain-source voltage of 30V and a continuous drain current rating of 20A at 25°C.



Key electrical characteristics include a maximum junction-to-case thermal resistance of 1.8°C/W and a maximum junction-to-pcb thermal resistance of 42°C/W. The MOSFET is designed for optimal RDS(on) x Qg trade-off at 4.5V, contributing to reduced switching and conduction losses.



This MOSFET is suitable for switching applications, particularly in DC-DC converters for computer and telecom systems. It integrates a monolithic Schottky diode and is packaged in a PowerSO-8 format, supplied on tape and reel.



Operating junction and storage temperatures range from -55°C to 150°C. The device also features a pulsed drain current of 80A and avalanche current capability.

STSJ100NHS3LL Quick Information

Product Type: MOSFET
Series: STripFET III
Canonical Name: N-channel 30V Power MOSFET
Subcategory: N-Channel

STSJ100NHS3LL Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

STSJ100NHS3LL Features

  • N-channel STripFET III Power MOSFET.
  • 30V drain-source voltage rating.
  • 20A continuous drain current.
  • PowerSO-8 package on tape and reel.
  • Optimized for reduced switching losses.

STSJ100NHS3LL Applications

  • Ideal for DC-DC converters.
  • Suitable for computer applications.
  • Used in telecom systems.
  • Synchronous switch applications.

STSJ100NHS3LL FAQs

5 frequently asked questions generated from this part’s specifications.
What is the drain-source voltage of the STSJ100NHS3LL MOSFET?

The drain-source voltage (VDS) is 30V.

What is the continuous drain current for the STSJ100NHS3LL at 25°C?

The continuous drain current at TC = 25°C is 20A.

What package type is the STSJ100NHS3LL MOSFET supplied in?

The STSJ100NHS3LL is supplied in a PowerSO-8 package on tape and reel.

What is the operating temperature range for the STSJ100NHS3LL?

The operating junction temperature ranges from -55°C to 150°C.

What technology does the STSJ100NHS3LL MOSFET use?

This MOSFET utilizes STripFET III technology.
