| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Industrial Grade | |
| Input Voltage Max | |
| Input Voltage Min | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Output Voltage Adjustment Range | |
| Overcurrent Protection | |
| Power (Watts) | |
| Remote On/Off | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Cosel STMGFS302412-N1 is an enclosed DC-DC converter designed for commercial ITE applications. It accepts a wide input voltage range of 18 to 76 VDC and provides a regulated single output of 12 VDC at 2.5 A, delivering up to 30 W of output power.
With a typical efficiency of 89% and 1.5 kV isolation voltage, this converter offers reliable performance. It includes overcurrent protection (auto recovery at 105% of rating) and a remote ON/OFF function (negative logic). The output voltage can be adjusted between 10.80 V and 13.20 V for flexibility.
Housed in a chassis-mount enclosed package measuring 117.1 mm x 52.1 mm x 26.9 mm, the converter operates over a temperature range of -20°C to 70°C with derating. It is CE approved and suitable for power distribution in information technology equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $97.74 | $97.74 |
| 5+ | $96.71 | $96.71 |
| 10+ | $96.23 | $96.23 |
| 25+ | $95.73 | $95.73 |
| 50+ | $95.35 | $95.35 |
| 100+ | $95.01 | $95.01 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 18 V to 76 V DC.
It provides a single output of 12 V DC at a maximum current of 2.5 A.
The typical efficiency is 89%.
The operating temperature range is -20°C to 70°C with derating.
It uses chassis mount with an enclosed case.
Yes, it has overcurrent protection that operates above 105% of rating and recovers automatically.
The part is listed as RoHS3 compliant, but this status is unverified and should be confirmed with the manufacturer.
