Mfr Part #:

STM32F030CCT6

Mfr Name: ST

The STM32F030CCT6 is a microcontroller from STMicroelectronics based on the Arm Cortex-M0 core, operating at up to 48 MHz. It offers 256 KB of Flash memory and 32 KB of SRAM.

✓ Total Stock: 11,511 pcs

$ Price Range: $5.52

STM32F030CCT6 Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Smaxon Electronics ✓ Non-Authorised Inventory information	9,000 pcs On Request	9000 pcs	On Request	1	On Request	On Request	20+	On Request	On Request
Romaks Technologies ✓ Non-Authorised Inventory information	2,511 pcs On Request	2511 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

STM32F030CCT6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	ST
Frequency	48 MHz
Lead Spacing	0.5 mm
Lead Style	Gull Wing
Operating Temperature	-40 to +85 °C
Operating Voltage	2.4 to 3.6 V

View Similar Products (0)

STM32F030CCT6 Description

Short technical summary and product information.

The STM32F030CCT6 is a microcontroller unit (MCU) from STMicroelectronics, built around the high-performance Arm Cortex-M0 32-bit RISC core. It operates at a frequency of up to 48 MHz, providing efficient processing capabilities for embedded applications.

This MCU features up to 256 KB of Flash memory and 32 KB of SRAM, supporting various communication interfaces including up to two I2C, two SPI, and six USART ports. It also includes a 12-bit ADC and multiple timers, such as seven general-purpose 16-bit timers and an advanced-control PWM timer.

The STM32F030CCT6 is designed for a wide operating temperature range of -40 to +85 °C and a power supply range of 2.4 to 3.6 V. Its comprehensive power-saving modes make it suitable for low-power applications. The device is available in a CCT6 package.

Applications for the STM32F030x4/x6/x8/xC series include application control, user interfaces, handheld equipment, PC peripherals, and industrial automation.

STM32F030CCT6 Quick Information

Product Type: Microcontroller

Series: STM32F0

Canonical Name: STM32F030CCT6 Microcontroller

Subcategory: Embedded Microcontroller

STM32F030CCT6 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

STM32F030CCT6 Estimated Pricing

Qty	Low	High
1+	$5.52	$5.52

Estimated market price range - modelled values for guidance only, not live distributor offers.

STM32F030CCT6 Features

Arm Cortex-M0 32-bit RISC core
Operates at up to 48 MHz frequency
256 KB Flash memory, 32 KB SRAM
Multiple I2C, SPI, and USART interfaces
Wide temperature range: -40 to +85 °C

STM32F030CCT6 Applications

Application control and user interfaces
Handheld equipment and portable devices
PC peripherals and gaming platforms
Industrial applications and PLCs
Alarm systems and video intercoms

STM32F030CCT6 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the core architecture of the STM32F030CCT6?

The STM32F030CCT6 features an Arm® Cortex®-M0 32-bit RISC core.

What is the maximum operating frequency of the STM32F030CCT6?

The STM32F030CCT6 operates at a frequency of up to 48 MHz.

How much Flash memory and SRAM does the STM32F030CCT6 have?

The STM32F030CCT6 has up to 256 KB of Flash memory and up to 32 KB of SRAM.

What are the operating temperature and voltage ranges for the STM32F030CCT6?

The STM32F030CCT6 operates in the -40 to +85 °C temperature range from a 2.4 to 3.6 V power supply.

What communication interfaces are available on the STM32F030CCT6?

The STM32F030CCT6 offers up to two I2C interfaces, up to two SPI interfaces, and up to six USART interfaces.

What is the RoHS status of the STM32F030CCT6?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the STM32F030CCT6?

The Moisture Sensitivity Level (MSL) is 1 Unlimited.
