| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,000 pcs
|
3000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Gate Charge (Qg) (Max) @ Vgs | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Supplier Device Package | |
| Supplier Package | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The STMicroelectronics STL7N6F7 is a single N-Channel MOSFET with a drain-source voltage rating of 60V and a continuous drain current capability of 7A at case temperature.
This MOSFET features a low on-resistance of 25mOhm maximum at 3.5A and 10V gate-source voltage. It has a gate charge of 8nC maximum at 10V and an input capacitance of 450pF maximum at 25V drain-source voltage. The gate threshold voltage is 4V maximum at 250µA.
Operating within a temperature range of -55°C to 150°C (TJ), the STL7N6F7 has a maximum power dissipation of 2.4W at ambient temperature. It is packaged in a 6-PowerWDFN (PowerFlat™ 2x2) case and designed for surface mounting.
Key electrical characteristics include a maximum gate-source voltage of ±20V. The technology used is MOSFET (Metal Oxide).
| Qty | Low | High |
|---|---|---|
| 1+ | $2.56 | $2.56 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage (Vdss) for the STL7N6F7 is 60V.
The STL7N6F7 has a continuous drain current of 7A.
The maximum on-resistance (Rds On) for the STL7N6F7 is 25mOhm at 3.5A and 10V.
The STL7N6F7 is an N-Channel MOSFET.
The STL7N6F7 is supplied in a 6-PowerWDFN package, also known as PowerFlat™ (2x2).
The operating temperature range for the STL7N6F7 is -55°C to 150°C.
