The STK544UC62K-E is a motor driver IC manufactured by ON Semiconductor, designed for 3-phase inverter applications. This hybrid IC operates with a maximum voltage of 450V and can handle an output current of 20A. It utilizes IGBT technology and includes features such as a bootstrap circuit for efficient operation.
The device is suitable for AC motor applications and offers fault protection against shoot-through and under-voltage lockout (UVLO). It interfaces via logic signals and is designed for through-hole mounting in a 23-SIP package.
Key electrical specifications include an operating supply voltage range of 0V to 450V, an output current of 10A (as per introtext, though other sources indicate 20A), and an operating supply current of 4mA. The operating temperature range is specified from -40°C to 150°C (TJ).
This component is packaged in a 23-SIP, 19 leads, formed leads configuration and is supplied in a tube. It is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum operating voltage is 450V.
The output current is 20A.
It uses IGBT technology.
The operating temperature range is -40°C to 150°C (TJ).
It is mounted using the through-hole method.
The package type is 23-SIP.
Yes, it is RoHS3 compliant.
