STG3820BJR The STMicroelectronics STG3820BJR is a 4-circuit analog switch featuring 5.8 Ohm on-resistance and a 1.65V to 4.3V operating voltage range. It comes in a 30-WFBGA, FCBGA package.
Mfr Part #:

STG3820BJR

Available from 1 distributors
Mfr Name: STMicroelectronics
STMicroelectronics
The STMicroelectronics STG3820BJR is a 4-circuit analog switch featuring 5.8 Ohm on-resistance and a 1.65V to 4.3V operating voltage range. It comes in a 30-WFBGA, FCBGA package.
✓ Total Stock: 10,000 pcs
$ Price Range: $0.30

STG3820BJR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
10,000 pcs
On Request
10000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

STG3820BJR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Bandwidth
Channel
Channel Capacitance (CS(off), CD(off))
Charge Injection
Crosstalk
Current
Industrial Grade
Medical Grade
Military Grade
Mounting Type
Multiplexer
Number of Circuits
On
Operating Temperature
Supplier Device Package
Switch Circuit
Switch Time (Ton, Toff) (Max)
Tape & Reel
Voltage
View Similar Products (0)

STG3820BJR Description

Short technical summary and product information.

The STMicroelectronics STG3820BJR is a dual-pole, double-throw (DPDT) analog switch designed for interface applications. It offers a low on-resistance of 5.8 Ohms and operates within a voltage range of 1.65V to 4.3V.



This device features 4 circuits and a 2:2 multiplexer configuration, with a bandwidth of 800MHz. Key electrical characteristics include a charge injection of 6.4pC and crosstalk of -78dB at 1MHz. The switch time (Ton, Toff) is rated at 15ns and 13ns respectively, with a channel capacitance of 2pF.



Packaged in a 30-WFBGA, FCBGA format, the STG3820BJR is designed for surface mount applications. It operates within an ambient temperature range of -40°C to 85°C. The component is specified with RoHS3 compliance and MSL 1 Unlimited moisture sensitivity level.

STG3820BJR Quick Information

Product Type: Analog Switch
Canonical Name: STMicroelectronics STG3820BJR Analog Switch
Subcategory: Analog Switches, Multiplexers, Demultiplexers

STG3820BJR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

STG3820BJR Estimated Pricing

Qty Low High
1+ $0.30 $0.30

Estimated market price range - modelled values for guidance only, not live distributor offers.

STG3820BJR Features

  • 4-circuit dual-pole double-throw analog switch.
  • Low 5.8 Ohm on-resistance.
  • Wide 1.65V to 4.3V operating voltage.
  • 800MHz bandwidth for signal integrity.
  • Surface mount 30-WFBGA, FCBGA package.

STG3820BJR Applications

  • Ideal for signal routing applications.
  • Suitable for low voltage systems.
  • Used in interface circuitry.
  • Effective for multiplexing tasks.

STG3820BJR FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating temperature range for the STG3820BJR?

-40°C to 85°C (TA)

What package type is the STG3820BJR supplied in?

30-WFBGA, FCBGA

What is the on-resistance of the STG3820BJR?

5.8 Ohms

What is the operating voltage range for this analog switch?

1.65V to 4.3V
