| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
95 pcs
|
95 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| SVHC Present | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Hirose Electric ST60-24P(30) is a 24-position receptacle connector designed for board-to-cable/wire applications. It features a 0.5mm pitch, single-row layout with all positions loaded, and uses non-gendered contacts with 30.0µin gold finish for reliable signal integrity.
The connector supports board edge, surface mount, and right-angle mounting styles, and terminates via solder. A latch holder fastening system provides secure mating, and the housing includes a board guide and shielding for enhanced performance. The insulation is black with a height of 3.00mm.
Rated for 0.5A per contact and 100VAC, the ST60-24P(30) operates over -30°C to 80°C. It is intended for compact electronic assemblies requiring a shielded, low-profile interconnect solution.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.22 | $3.22 |
| 10+ | $2.74 | $2.74 |
| 25+ | $2.45 | $2.45 |
| 100+ | $2.33 | $2.33 |
| 250+ | $2.19 | $2.19 |
| 500+ | $2.15 | $2.15 |
| 1,500+ | $2.15 | $2.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 0.50mm.
It has 24 positions, all loaded.
The current rating is 0.5A per contact.
The voltage rating is 100VAC.
Board edge, surface mount, and right angle.
