ST203C107MAJ05 100µF 25V X7R surface mount MLCC from Kyocera AVX in a stacked SMD J-Lead package with ultra-low ESR.
Mfr Part #:

ST203C107MAJ05

Available from 1 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
100µF 25V X7R surface mount MLCC from Kyocera AVX in a stacked SMD J-Lead package with ultra-low ESR.
✓ Total Stock: 24 pcs
$ Price Range: $49.06 - $62.62

ST203C107MAJ05 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
24 pcs
On Request
24 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

ST203C107MAJ05 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Capacitance
Dielectric Withstanding Voltage
Dissipation Factor
Features
Lead Spacing
Lead Style
Length
Mounting Type
Operating Temperature
Tape & Reel
Temperature Coefficient
Thickness (Max)
Tolerance
Voltage
Width
View Similar Products (0)

ST203C107MAJ05 Description

Short technical summary and product information.

The ST203C107MAJ05 is a 100µF, 25V rated, X7R dielectric ceramic capacitor from Kyocera AVX's TurboCap series. It features a stacked SMD construction with J-Lead terminations, designed for surface mount assembly. The X7R temperature coefficient provides a capacitance change of ±15% over the -55°C to +125°C operating temperature range.



This capacitor offers ultra-low ESR values: 0.003Ω typical at 10KHz, 0.0015Ω at 50KHz, and 0.001Ω at 100KHz. Maximum dissipation factor is 2.5% at 25°C and 1KHz. Minimum insulation resistance is 500 MΩ-µF at 25°C and 50 MΩ-µF at 125°C. Dielectric withstanding voltage is 250% of rated voltage for 5 seconds.



The part is housed in a Stacked SMD, 10 J-Lead package measuring 13.34mm x 7.62mm with a maximum thickness of 5.59mm. It is intended for SMPS filtering, bypass, and decoupling applications where low ESL is critical.

ST203C107MAJ05 Quick Information

Product Type: MLCC Capacitor
Series: ST20
Canonical Name: ST203C107MAJ05 Kyocera AVX 100µF 25V X7R Surface Mount MLCC
Subcategory: Stacked MLCC

ST203C107MAJ05 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

ST203C107MAJ05 Estimated Pricing

Qty Low High
1+ $62.62 $62.62
10+ $52.94 $52.94
48+ $49.06 $49.06

Estimated market price range - modelled values for guidance only, not live distributor offers.

ST203C107MAJ05 Features

  • 100µF capacitance with ±20% tolerance.
  • Rated for 25V DC operation.
  • Ultra-low ESR down to 0.001Ω typical.
  • X7R dielectric with ±15% temperature stability.
  • Stacked SMD J-Lead package for stress relief.

ST203C107MAJ05 Applications

  • Ideal for SMPS input and output filtering.
  • Used for bypass and decoupling circuits.
  • Suitable for high ripple current applications.
  • Designed for high frequency power conversion.

ST203C107MAJ05 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the capacitance and tolerance of the ST203C107MAJ05?

The capacitance is 100 µF with a tolerance of ±20%.

What is the rated voltage of this capacitor?

The rated voltage is 25V DC.

What is the temperature coefficient and operating temperature range?

The temperature coefficient is X7R, with an operating temperature range of -55°C to +125°C.

What is the package type and mounting style?

The package is Stacked SMD, 10 J-Lead, with surface mount MLCC mounting.

What are the typical ESR values?

Typical ESR is 0.003Ω at 10KHz, 0.0015Ω at 50KHz, and 0.001Ω at 100KHz.

Is this capacitor RoHS compliant?

According to the datasheet, this part is not RoHS compliant.

What applications is this capacitor designed for?

It is designed for SMPS filtering, bypass, and decoupling applications.
