Mfr Part #:

ST-RJ45-R-MIN

The Schmalz Inc ST-RJ45-R-MIN is a compact RJ45 breakout board with screw terminals. It breaks out all 8 contacts and the shield for easy termination.

✓ Total Stock: 7 pcs

$ Price Range: $9.99

ST-RJ45-R-MIN Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
ADI/AAR OEM Supply ✓ Non-Authorised Inventory information	7 pcs On Request	7 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

ST-RJ45-R-MIN Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Schmalz Inc
Connector	8P8C + Shield
Mounting Type	Screw Terminal Breakout Board
Tape & Reel	No
Temperature Rating	-25°C to +70°C

View Similar Products (0)

ST-RJ45-R-MIN Description

Short technical summary and product information.

The Schmalz Inc ST-RJ45-R-MIN is a compact RJ45 breakout board designed for efficient wire termination. It provides screw terminals for all 8 contacts of the 8P8C connector, plus the shield, allowing for fast and secure connections.

This mini breakout board is ideal for applications where space is limited, thanks to its compact form factor. It supports a wire range of 16-24 AWG for both stranded and solid wires. The PCB features an LF HASL surface finish and operates within a temperature range of -25°C to +70°C.

Designed for ease of use, the ST-RJ45-R-MIN includes mounting holes for secure fixturing, ensuring a stable connection. This breakout board facilitates convenient access to all RJ45 contacts, simplifying prototyping and integration into various electronic projects.

ST-RJ45-R-MIN Quick Information

Product Type: RJ45 Breakout Board

Canonical Name: RJ45 Mini Screw Terminal Breakout Board

Subcategory: Terminal Block Adapters

ST-RJ45-R-MIN Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

ST-RJ45-R-MIN Estimated Pricing

Qty	Low	High
1+	$9.99	$9.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

ST-RJ45-R-MIN Features

Breaks out all 8 contacts and shield.
Screw terminals for fast connections.
Compact form factor for tight spaces.
Mounting holes for secure fixturing.
Supports 16-24 AWG wire range.

ST-RJ45-R-MIN Applications

Facilitates RJ45 signal access.
Simplifies prototyping and testing.
Ideal for embedded systems.
Suitable for custom network interfaces.

ST-RJ45-R-MIN FAQs

6 frequently asked questions generated from this part’s specifications.

What wire range does the terminal block adapter support?

It supports wire ranges from 16-24 AWG for both stranded and solid wires.

What is the operating temperature range of the device?

-25°C to 70°C.

What type of connector does this adapter use?

It uses an 8P8C + Shield connector.

What surface finish does the PCB have?

LF HASL.

What is the mounting type for this terminal block adapter?

Screw terminal breakout board.

Is this product RoHS compliant?

It is marked as RoHS3 compliant, but this status is unverified.
