| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
227 pcs
|
227 pcs | On Request | 1 | On Request | On Request | 614 | On Request | On Request | |
|
215 pcs
|
215 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Plating Option | |
| Row Option | |
| Row Spacing | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Samtec SSW-106-01-T-D is a 12 position, double row receptacle from the SSW series. It features forked contacts with matte tin plating over 50 µ" nickel underplate, housed in a black liquid crystal polymer insulator rated UL94 V-0. The connector uses a push-pull fastening system and is designed for board-to-board or cable applications.
Electrical ratings include 4.7A per contact (with 2 pins powered) and a voltage rating of 465 VAC / 655 VDC. The operating temperature range is -55°C to +105°C for tin plated versions. The through hole termination with solder tails (2.64mm contact length) provides reliable mechanical attachment.
The 2.54mm pitch and 2.54mm row spacing are standard for many prototyping and production designs. The connector mates with Samtec TSW, MTSW, MTLW, DW, EW, ZW, TSS, ZSS, TSM, TSSH, and HTSS series headers.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.01 | $1.01 |
| 250+ | $0.96 | $0.96 |
| 500+ | $0.87 | $0.87 |
| 1,000+ | $0.83 | $0.83 |
| 2,500+ | $0.67 | $0.67 |
| 5,000+ | $0.59 | $0.59 |
| 10,000+ | $0.47 | $0.47 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 12 positions arranged in 2 rows, all positions loaded.
The current rating is 4.7A per contact (with 2 pins powered).
The voltage rating is 465 VAC / 655 VDC.
It is a through hole mounting connector with solder termination.
