| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
29 pcs
|
29 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Fastening Type | |
| Halogen Free | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Lead-Free Solderable | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| Plating Option | |
| Row Option | |
| Row Spacing | |
| SVHC Present | |
| Standard Package Quantity | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Samtec SSQ-132-03-T-D is a 64-position through-hole receptacle socket strip from the Tiger Buy SSQ series. It features a double-row configuration with a 2.54mm pitch and 2.54mm row spacing, designed for board-to-board or cable applications. The connector uses forked phosphor bronze contacts with a matte tin plating and is housed in a black high-temperature thermoplastic insulator rated UL94 V-0.
This socket strip is rated for 6.3A per pin (with 2 pins powered) and has a voltage rating of 465 VAC / 655 VDC. It operates over a temperature range of -55°C to +105°C when using tin plating. The through-hole termination with solder tails (10.00mm contact length) provides reliable mechanical attachment to the PCB.
The SSQ-132-03-T-D mates with Samtec TSW, MTSW, MTLW, and other compatible header series. It is lead-free solderable and supplied in bulk packaging.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.08 | $6.08 |
| 25+ | $5.89 | $5.89 |
| 50+ | $5.75 | $5.75 |
| 100+ | $5.24 | $5.24 |
| 500+ | $4.19 | $4.19 |
| 1,000+ | $3.83 | $3.83 |
| 2,500+ | $3.50 | $3.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SSQ-132-03-T-D has 64 positions, all loaded, in a double-row configuration.
The pitch is 2.54mm (0.100") with a row spacing of 2.54mm (0.100").
The current rating is 6.3A per pin with 2 pins powered, per the datasheet for the SSQ/TSW mating pair.
The voltage rating is 465 VAC / 655 VDC.
The mounting type is through-hole with solder termination.
The operating temperature range is -55°C to +105°C with tin plating.
The contact material is phosphor bronze with a matte tin plating.
