| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
249 pcs
|
249 pcs | On Request | 1 | On Request | On Request | 515 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating (2 pins powered) | |
| Fastening Type | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Cycles | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Packaging Type | |
| Pitch | |
| Style | |
| Termination | |
| Voltage Rating |
The Samtec SSQ-130-01-S-S is a 30 position single row receptacle socket strip from the SSQ series. It features a 2.54mm (0.100") pitch and through hole mounting with solder termination. The connector uses forked contacts made of phosphor bronze with a tin finish (30.0µin).
The insulator is black liquid crystal polymer rated UL94 V-0. The connector supports board to board or cable style connections with push-pull fastening. It has an operating temperature range of -55°C to +125°C and is rated for 6.3A per pin (2 pins powered) with a voltage rating of 465VAC / 655VDC.
The part is packaged in bulk and is lead-free solderable for -S row option. It mates with Samtec TSW, MTSW, MTLW, and other series headers.
| Qty | Low | High |
|---|---|---|
| 1+ | $8.17 | $8.17 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
30 positions in a single row.
2.54mm (0.100").
6.3A per pin with 2 pins powered.
465VAC / 655VDC.
Through hole with solder termination.
