SSM2019BRNZRL The SSM2019BRNZRL is a latest generation audio preamplifier from Analog Devices, offering excellent audio performance with ultralow noise and distortion. It is housed in a PDIP-8 package.
Mfr Part #:

SSM2019BRNZRL

Available from 3 distributors
Mfr Name: ADI Electronics
ADI Electronics
The SSM2019BRNZRL is a latest generation audio preamplifier from Analog Devices, offering excellent audio performance with ultralow noise and distortion. It is housed in a PDIP-8 package.
✓ Total Stock: 8,540 pcs
$ Price Range: $5.24

SSM2019BRNZRL Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
7,000 pcs
On Request
7000 pcs On Request 1 On Request On Request 24+ On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
1,500 pcs
On Request
1500 pcs On Request 1 On Request On Request 21+ On Request On Request
Fe Components ✓
Non-Authorised Inventory information
40 pcs
On Request
40 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SSM2019BRNZRL Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Storage Temperature
Tape & Reel
View Similar Products (0)

SSM2019BRNZRL Description

Short technical summary and product information.

The SSM2019BRNZRL is a monolithic audio preamplifier designed by Analog Devices, combining advanced processing with preamplifier design expertise. It requires only one external gain-setting resistor or potentiometer and is unity-gain stable.



Key electrical specifications include ultralow noise with a 1.5 dB noise figure and 950 pV/√Hz, and very low total harmonic distortion (THD) of less than 0.01% at a gain of 100 over the full audio band. It also features a wide bandwidth of 1 MHz at G=100 and a high slew rate of 20 V/µs (typical).



This device operates over an extended temperature range of -40°C to +85°C and supports a positive supply voltage from +10V to +36V. Its applications include microphone preamplifiers and bus summing amplifiers in professional and consumer audio equipment, sonar, and other systems requiring a low-noise instrumentation amplifier with high gain capability.



The SSM2019BRNZRL is available in an 8-pin PDIP package, suitable for through-hole mounting.

SSM2019BRNZRL Quick Information

Product Type: Audio Preamplifier
Canonical Name: SSM2019BRNZRL Audio Preamplifier
Subcategory: Linear Regulator Controllers

SSM2019BRNZRL Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SSM2019BRNZRL Estimated Pricing

Qty Low High
1+ $5.24 $5.24

Estimated market price range - modelled values for guidance only, not live distributor offers.

SSM2019BRNZRL Features

  • Ultralow noise performance: 1.5 dB noise figure.
  • Very low THD: <0.01% at G = 100.
  • Wide bandwidth: 1 MHz at G = 100.
  • High slew rate: 20 V/µs typical.
  • Extended temperature range: -40°C to +85°C.

SSM2019BRNZRL Applications

  • Ideal for microphone preamplifiers.
  • Suitable for bus summing amplifiers.
  • Used in professional audio equipment.
  • Applicable in consumer audio systems.
  • Can be used in sonar applications.

SSM2019BRNZRL FAQs

5 frequently asked questions generated from this part’s specifications.
What is the typical noise figure of the SSM2019BRNZRL?

The typical noise figure is 1.5 dB.

What is the typical THD+N at 1kHz for the SSM2019BRNZRL?

The typical THD+N at 1kHz is 0.005%.

What is the operating supply voltage range for the SSM2019BRNZRL?

The positive supply voltage range is +10V to +36V.

What is the operating temperature range of the SSM2019BRNZRL?

The operating temperature range is -40°C to +85°C.

What package is the SSM2019BRNZRL supplied in?

The SSM2019BRNZRL is supplied in a PDIP-8 package.
