SSM-105-L-SH-TR 5 Position Receptacle from Samtec with female socket contacts, 2.54mm pitch, surface mount right angle termination. Rated for 5.2A per contact and 405VAC/572VDC.
Mfr Part #:

SSM-105-L-SH-TR

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
5 Position Receptacle from Samtec with female socket contacts, 2.54mm pitch, surface mount right angle termination. Rated for 5.2A per contact and 405VAC/572VDC.
✓ Total Stock: 606 pcs
$ Price Range: $0.90 - $1.94

SSM-105-L-SH-TR Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
606 pcs
On Request
606 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SSM-105-L-SH-TR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

SSM-105-L-SH-TR Description

Short technical summary and product information.

The SSM-105-L-SH-TR is a 5-position receptacle connector from Samtec. It features female socket contacts with tin finish, designed for board-to-board or cable applications. The connector has a push-pull fastening type and is rated for 5.2A per contact with a voltage rating of 405VAC and 572VDC. It operates over a temperature range of -55°C to 125°C. The insulation is black with a height of 3.18mm. The connector is surface mount, right angle orientation, with solder termination. The pitch is 2.54mm (0.100 inches). All 5 positions are loaded in a single row. The packaging is Tape & Reel (inferred). This connector is suitable for applications requiring a compact, reliable interconnect solution.

SSM-105-L-SH-TR Quick Information

Product Type: Receptacle
Series: SSM
Canonical Name: Samtec SSM-105-L-SH-TR - 5 Position Receptacle, Female Socket, Surface Mount Right Angle, 2.54mm Pitch
Subcategory: Female Socket Receptacles

SSM-105-L-SH-TR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SSM-105-L-SH-TR Estimated Pricing

Qty Low High
1+ $1.94 $1.94
50+ $1.88 $1.88
100+ $1.58 $1.58
600+ $1.18 $1.18
1,200+ $1.03 $1.03
1,800+ $1.00 $1.00
4,800+ $0.90 $0.90

Estimated market price range - modelled values for guidance only, not live distributor offers.

SSM-105-L-SH-TR Features

  • 5 position single row receptacle.
  • 2.54mm pitch for compact designs.
  • Rated for 5.2A per contact.
  • Surface mount right angle termination.
  • Push-pull fastening type.

SSM-105-L-SH-TR Applications

  • Board-to-board interconnect applications.
  • Cable-to-board connections.
  • Compact electronic assemblies.
  • Industrial control systems.
  • Automotive electronics.

SSM-105-L-SH-TR FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the SSM-105-L-SH-TR have?

5 positions, all loaded.

What is the pitch of this connector?

2.54mm (0.100 inches).

What is the current rating per contact?

5.2A per contact.

What is the voltage rating?

405VAC and 572VDC.

What is the mounting type?

Surface mount, right angle.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Tin with 0.25µm thickness.
