| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Capacitance | |
| Color | |
| Current | |
| Features | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Range | |
| Storage Temperature | |
| Style | |
| Tape & Reel | |
| Terminal Type | |
| Turn Off Time | |
| Turn On Time | |
| Type | |
| Voltage | |
| Weight |
The Celduc SSC24306 is a DC solid state output module designed for reliable switching applications. It offers a maximum load current of 3A and a maximum load voltage of 60VDC, making it suitable for various industrial and electronic systems.
This module operates with a nominal control voltage of 24VDC, with a control voltage range of 8-40VDC. It features a fast turn-on time of 100µs and a turn-off time of 700µs. The SSC24306 boasts high immunity to external interference and a low leakage current of 1mA in the off-state, ensuring stable performance.
Designed for PCB mounting, this solid state relay provides a compact solution for control systems. Its operating temperature range is -40°C to +90°C, and it has an input-output isolation voltage of 4000 VRMS.
Key specifications include a 3A nominal current, 60VDC peak voltage, and a 1.5VDC on-state voltage drop. The module also features a status LED for visual indication.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum load current is 3A.
The maximum load voltage is 60V dc.
The control voltage range is 8-40V dc.
The operating temperature range is -40°C to +90°C.
The turn-on time is 100 µs.
The turn-off time is 700 µs.
The off-state leakage current is 1 mA.
