| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Dielectric Withstanding Voltage | |
| Fastening Type | |
| Heat Deflection Temp | |
| Insertion Depth | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Size Range | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Plating | |
| SVHC Present | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The Samtec SSA-107-S-T is a 7 position, single row, through hole receptacle socket from the SSA series. It features a 2.54mm (0.100") pitch and a push-pull fastening type, designed for board-to-board applications. The connector uses a black PET polyester insulator with a UL94 V-0 flammability rating and operates over a temperature range of -55°C to +105°C.
The contacts are made of phosphor bronze with a matte tin plating over a 50 µ" (1.27 µm) nickel underplate. The socket accepts leads with a diameter range of 0.38 mm to 0.56 mm and supports an insertion depth of 1.27 mm to 3.30 mm. It is rated for 1000V and has a dielectric withstanding voltage of 1000 VRMS.
The SSA series features a snap-strip design and standoffs for easy board cleaning. This connector is solder terminated and is lead-free solderable for wave soldering processes only.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.01 | $1.01 |
| 50+ | $0.99 | $0.99 |
| 100+ | $0.76 | $0.76 |
| 500+ | $0.68 | $0.68 |
| 1,000+ | $0.50 | $0.50 |
| 2,000+ | $0.47 | $0.47 |
| 5,000+ | $0.43 | $0.43 |
| 10,000+ | $0.35 | $0.35 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SSA-107-S-T has 7 positions in a single row.
The pitch is 2.54 mm (0.100").
The voltage rating is 1000V.
The mounting type is through hole.
The operating temperature range is -55°C to +105°C.
The contact material is phosphor bronze with a matte tin plating over 50 µ" (1.27 µm) nickel.
The insulator is black PET polyester with a UL94 V-0 flammability rating.
