SS71800-027F The SS71800-027F is a shielded RJ45 modular jack with 8p8c contacts, vertical orientation, and through hole mounting. It features gold plated contacts and board lock for secure attachment.
Mfr Part #:

SS71800-027F

Available from 1 distributors
Mfr Name: Stewart Connector
Stewart Connector
The SS71800-027F is a shielded RJ45 modular jack with 8p8c contacts, vertical orientation, and through hole mounting. It features gold plated contacts and board lock for secure attachment.
✓ Total Stock: 160 pcs
$ Price Range: $1.78 - $2.83

SS71800-027F Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
AA2DE ✓
Non-Authorised Inventory information
160 pcs
On Request
160 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SS71800-027F Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Material
Features
LED Color
Mounting Type
Number of Ports
Number of Positions
Number of Rows
Orientation
Ratings
SVHC Present
Shielding
Tab Direction
Termination
View Similar Products (0)

SS71800-027F Description

Short technical summary and product information.

The SS71800-027F is a modular jack connector from Stewart Connector, designed for Ethernet applications. It features an 8p8c (RJ45) contact arrangement with a single port and single row. The connector is mounted via through hole technology with a vertical orientation and solder termination. It is fully shielded for EMI protection and includes a board lock feature for secure PCB attachment. The contacts are made of copper alloy with a gold finish, ensuring reliable connectivity over repeated mating cycles. The connector is rated for Cat5e performance and has a user-selectable tab direction. It does not contain an LED indicator. This jack is suitable for use in networking equipment, patch panels, and other data communication systems requiring a robust, shielded RJ45 interface.

SS71800-027F Quick Information

Product Type: Modular Connector Jack
Series: SS71800
Canonical Name: Modular Jack, RJ45, 8p8c, Vertical, Shielded, Through Hole
Subcategory: RJ45

SS71800-027F Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SS71800-027F Estimated Pricing

Qty Low High
1+ $2.83 $2.83
10+ $2.36 $2.36
25+ $2.24 $2.24
50+ $2.15 $2.15
100+ $2.02 $2.02
250+ $1.85 $1.85
500+ $1.78 $1.78

Estimated market price range - modelled values for guidance only, not live distributor offers.

SS71800-027F Features

  • Shielded RJ45 modular jack for EMI protection.
  • Vertical through hole mounting for PCB design.
  • Gold plated contacts for reliable connectivity.
  • Board lock feature for secure attachment.
  • Cat5e rated for Ethernet applications.

SS71800-027F Applications

  • Used in networking switches and routers.
  • Ideal for Ethernet patch panels.
  • Suitable for industrial control equipment.
  • Common in telecommunications infrastructure.

SS71800-027F FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

8p8c (RJ45, Ethernet).

What is the mounting type?

Through hole.

Is the connector shielded?

Yes, shielded.

What is the orientation?

Vertical.

What is the contact finish?

Gold.

What is the performance rating?

Cat5e.

Does it have an LED?

No, it does not contain an LED.
