| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,000 pcs
|
4000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
494 pcs
|
494 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
493 pcs
|
493 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Frequency | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Freq | |
| Saturation Current (ISAT) | |
| Shielding | |
| Tape & Reel | |
| Tolerance | |
| Type | |
| Width |
The Bourns SRU8043-680Y is a shielded surface mount power inductor from the SRU8043 series. It offers a nominal inductance of 68 µH with a tolerance of ±30% and a typical DC resistance of 192 mΩ.
This inductor is designed for applications requiring stable power delivery, with a rated current of 1.2 A (Irms) and a saturation current (Isat) of 1 A. It features a drum core construction with a ferrite material and operates effectively within a temperature range of -40°C to 125°C.
The component has a compact size with dimensions of 8.00mm x 8.00mm and a height of 4.60mm, making it suitable for space-constrained designs. It is supplied in a tape and reel package containing 1000 pieces.
Key electrical characteristics include a Q factor of 20 at 2.52 MHz and a minimum self-resonant frequency of 7 MHz. The inductor is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.53 | $0.53 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance of the SRU8043-680Y is 68 µH.
The SRU8043-680Y has a rated current of 1.2 A (Irms) and a saturation current of 1 A.
The typical DC resistance (DCR) for the SRU8043-680Y is 192 mΩ.
The operating temperature range for the SRU8043-680Y is -40°C to 125°C.
The SRU8043-680Y has dimensions of 8.00mm x 8.00mm with a height of 4.60mm.
The SRU8043-680Y is supplied in a tape and reel package with 1000 pieces per reel.
