SRU1048A-100Y Bourns SRU1048A-100Y is a shielded ferrite drum core wirewound fixed inductor with 10µH inductance ±30%, 4.5A RMS current rating, and 25mOhm max DCR, designed for surface mount applications.
Mfr Part #:

SRU1048A-100Y

Available from 1 distributors
Mfr Name: Bourns
Bourns
Bourns SRU1048A-100Y is a shielded ferrite drum core wirewound fixed inductor with 10µH inductance ±30%, 4.5A RMS current rating, and 25mOhm max DCR, designed for surface mount applications.
✓ Total Stock: 250 pcs
$ Price Range: $0.18

SRU1048A-100Y Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
250 pcs
250 pcs On Request 1 On Request On Request On Request On Request On Request

SRU1048A-100Y Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Core Material
Current
Current Rating (Amps)
DC Resistance (DCR)
Frequency
Halogen Free
Height
Inductance
Inductance Range
Length
Material
Mounting Type
Operating Temperature
Q @ Freq
Ratings
SVHC Present
Shielding
Temperature Rise
Tolerance
Type
Width

SRU1048A-100Y Description

Short technical summary and product information.

The Bourns SRU1048A-100Y is a fixed inductor from the SRU1048A series, featuring a shielded ferrite drum core and wirewound construction. It offers an inductance of 10 µH with a tolerance of ±30% measured at 100 KHz / 1 V. The inductor is rated for a continuous RMS current of 4.5 A and a saturation current of 3.7 A, with a DC resistance of 25 mΩ max. The self-resonant frequency is typ 16 MHz, and the Q factor is 26 typ at 2.52 MHz.



This component is qualified to AEC-Q200 automotive standard, making it suitable for automotive electronics. It is halogen-free and RoHS3 compliant. The operating temperature range spans from -40°C to +125°C. The temperature rise at rated RMS current is typ 30°C, and inductance drop at saturation is typ 35%.



The inductor is packaged in a nonstandard surface mount package measuring 10.00mm x 10.00mm x 5.10mm. It is supplied on tape and reel with 600 pieces per reel. The terminal finish is silver/nickel/tin (Ag/Ni/Sn), and the winding is made of enameled copper wire.

SRU1048A-100Y Quick Information

Product Type: Fixed Inductor
Series: SRU1048A
Canonical Name: SRU1048A-100Y Fixed Inductor
Subcategory: Shielded Wirewound Inductor

SRU1048A-100Y Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

SRU1048A-100Y Estimated Pricing

Qty Low High
1+ $0.18 $0.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

SRU1048A-100Y Features

  • Shielded ferrite drum core wirewound construction.
  • 10µH inductance with ±30% tolerance at 100KHz.
  • 4.5A RMS and 3.7A saturation current ratings.
  • AEC-Q200 qualified for automotive applications.
  • Surface mount in 10mm x 10mm x 5.1mm package.

SRU1048A-100Y Applications

  • Used in DC-DC converter modules.
  • Suitable for automotive ECU applications.
  • Ideal for power supply filtering.
  • Used in EMI filter circuits.

SRU1048A-100Y FAQs

7 frequently asked questions generated from this part’s specifications.
What is the inductance of the SRU1048A-100Y?

10 µH ±30% at 100 KHz / 1 V.

What are the current ratings?

RMS current rating is 4.5 A, saturation current is 3.7 A.

What is the DC resistance?

Maximum DCR is 25 mOhm.

What is the self-resonant frequency?

Typical 16 MHz.

What is the package size and mounting type?

Surface mount, nonstandard package, dimensions 10.00mm x 10.00mm x 5.10mm.

Is the inductor shielded?

Yes, it is shielded.

What is the operating temperature range?

-40°C to +125°C.
