| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Halogen Free | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| Shielding | |
| Tape & Reel | |
| Tolerance | |
| Width |
The Bourns SRR0745A-330M is a shielded power inductor from the SRR0745A series, designed for demanding applications requiring reliable performance. It features a 33µH inductance with a ±20% tolerance and a maximum DC resistance of 150mΩ.
This inductor is rated for a current of 1.35A and a saturation current of 1.45A, operating within a temperature range of -40°C to 125°C. Its construction utilizes a ferrite core and enameled copper wire, providing shielded performance to minimize electromagnetic interference.
The SRR0745A-330M is AEC-Q200 qualified, making it suitable for automotive and other high-reliability applications. It is packaged in a compact 7.3 x 7.3 x 4.5 mm SMD (Surface Mount Device) package, supplied on a reel of 1000 pieces.
Key electrical specifications include an inductance of 33µH at 1kHz/1V, a DCR of 150mΩ max, and a rated current of 1.35A. The operating temperature range is -40°C to +125°C. Its shielded construction and AEC-Q200 qualification ensure robust performance in various environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.18 | $0.18 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
33 µH at 1 kHz/1 V.
1.35 A maximum.
150 mOhm maximum.
-40°C to 125°C.
Yes, it is shielded.
Yes, it is AEC-Q200 rated.
Yes, it is halogen free.
