| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9 pcs
|
9 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Q200 Qualified | |
| AEC Qualified | |
| Automotive Grade | |
| Core Material | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Halogen Free | |
| Height | |
| Inductance | |
| Inductance Drop | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Ratings | |
| SVHC Present | |
| Shielding | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Rise | |
| Terminal Finish | |
| Tolerance | |
| Type | |
| Width | |
| Wire Material |
This Bourns SRR0735A-390M is a shielded power inductor from the SRR0735A series, designed for demanding applications. It offers a nominal inductance of 39µH with a tolerance of ±20% and a rated current of 950mA (RMS) or 960mA (saturation).
The inductor has a low DC resistance (DCR) of 250mOhm maximum, minimizing power loss. It is constructed with a ferrite core and enameled copper wire, featuring a shielded design for reduced electromagnetic interference.
This component is AEC-Q200 qualified, making it suitable for automotive and other high-reliability applications. It is designed for surface mounting and comes in a standard package of 1500 pieces per reel.
Operating temperature ranges from -40°C to +125°C, with a typical temperature rise of 40°C at rated current. The inductance drop at saturation is typically 25%.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.18 | $0.18 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance value is 39µH.
The current rating is 950mA RMS.
The maximum DC resistance is 250mOhm.
Yes, it is AEC-Q200 qualified.
It features a shielded, drum core, wirewound construction.
The operating temperature range is -40°C to +125°C.
It is a surface mount component.
