SRP6540-1R0M The Bourns SRP6540-1R0M is a shielded power inductor with a 1µH inductance value and a 13.5A current rating. It features a low 7.2mΩ DCR and a surface mount package.
Mfr Part #:

SRP6540-1R0M

Available from 1 distributors
Mfr Name: Bourns
Bourns
The Bourns SRP6540-1R0M is a shielded power inductor with a 1µH inductance value and a 13.5A current rating. It features a low 7.2mΩ DCR and a surface mount package.
✓ Total Stock: 4,800 pcs
$ Price Range: $0.18

SRP6540-1R0M Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
4,800 pcs
4800 pcs On Request 1 On Request On Request On Request On Request On Request

SRP6540-1R0M Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Current Rating (Amps)
DC Resistance (DCR)
Halogen Free
Height
Inductance
Length
Material
Mounting Type
Operating Temperature
Shielding
Tape & Reel
Temperature Rise
Test Frequency
Tolerance
Type
Width

SRP6540-1R0M Description

Short technical summary and product information.

The Bourns SRP6540-1R0M is a shielded power inductor from the SRP6540 series, designed for demanding applications. It offers a nominal inductance of 1µH with a tolerance of ±20%, and a low DC resistance (DCR) of 7.2mΩ maximum.



This inductor is constructed with an iron powder core and features shielded construction for reduced electromagnetic interference. It has a rated current of 13.5A (Isat) and a temperature rise of 40°C typical at the rated Irms current. The operating temperature range is -55°C to 125°C.



Designed for surface mounting, the SRP6540-1R0M has dimensions of 7.20mm L x 6.50mm W x 4.00mm H. It is suitable for use in DC/DC converters and power supplies for portable communications equipment, laptop computers, camcorders, HDTVs, and video game consoles.



The inductor is supplied in a standard package of 1200 pieces per 13-inch reel and is RoHS3 compliant and halogen-free.

SRP6540-1R0M Quick Information

Product Type: Shielded Power Inductor
Series: SRP6540
Canonical Name: Bourns SRP6540-1R0M Shielded Power Inductor
Subcategory: Shielded

SRP6540-1R0M Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SRP6540-1R0M Estimated Pricing

Qty Low High
1+ $0.18 $0.18

Estimated market price range - modelled values for guidance only, not live distributor offers.

SRP6540-1R0M Features

  • Shielded construction for reduced EMI.
  • Iron powder core for high saturation current.
  • 1µH inductance with ±20% tolerance.
  • Rated for 13.5A saturation current.
  • Surface mountable for compact designs.

SRP6540-1R0M Applications

  • Ideal for DC/DC converters.
  • Used in portable electronics power.
  • Suitable for laptop computer power.
  • Applicable to HDTV power supplies.
  • Designed for video game consoles.

SRP6540-1R0M FAQs

7 frequently asked questions generated from this part’s specifications.
What is the inductance of the Bourns SRP6540-1R0M?

The inductance is 1 µH with a tolerance of ±20%.

What is the DC resistance (DCR) of this inductor?

The maximum DC resistance is 7.2 mΩ.

What is the current rating for the SRP6540-1R0M?

The saturation current (Isat) is typically 13.5A, and the RMS current (Irms) is typically 12A.

What is the operating temperature range for this Bourns inductor?

The operating temperature range is -55°C to 125°C.

How is the Bourns SRP6540-1R0M mounted?

It is designed for surface mounting.

What type of core does the SRP6540-1R0M use?

It uses an iron powder core.

What are the physical dimensions of the SRP6540-1R0M?

The dimensions are 7.20mm in length, 6.50mm in width, and 4.00mm in height.
