SRF1006-102Y The Bourns SRF1006-102Y is a common mode choke designed for signal line filtering. It features a 1mH inductance at 100kHz and a 50V DC rating.
Mfr Part #:

SRF1006-102Y

Available from 1 distributors
Mfr Name: Bourns
Bourns
The Bourns SRF1006-102Y is a common mode choke designed for signal line filtering. It features a 1mH inductance at 100kHz and a 50V DC rating.
✓ Total Stock: 1 pcs
$ Price Range: $0.99

SRF1006-102Y Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SRF1006-102Y Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Core Material
Current Rating (Max)
DC Resistance (DCR) (Max)
Filter Type
Height
Height (Max)
Impedance @ Frequency
Inductance @ Frequency
Length
Mounting Type
Number of Lines
Operating Temperature
Storage Temperature
Voltage Rating
Width
View Similar Products (0)

SRF1006-102Y Description

Short technical summary and product information.

The Bourns SRF1006-102Y is a surface mount common mode choke from the SRF1006 series, designed for EMI suppression in signal lines. It offers an inductance of 1mH at 100kHz and a maximum current rating of 520mA.



This component operates within a temperature range of -40°C to 105°C and has a DC resistance of 180mΩ maximum. Its impedance is rated at 1.4kΩ at 1MHz. The choke is housed in a horizontal, 4-pad SMD package with dimensions of 10.00mm x 8.70mm x 6.50mm.



Key electrical specifications include a 50V DC voltage rating and 2 lines. The construction utilizes a ferrite core, phenolic base, enameled copper wire, and Sn terminal coating. It is supplied in an 800-piece reel.



This common mode choke is suitable for applications requiring effective EMI suppression and signal integrity maintenance.

SRF1006-102Y Quick Information

Product Type: Common Mode Choke
Series: SRF1006
Canonical Name: Bourns SRF1006 Series Common Mode Choke
Subcategory: Common Mode Choke

SRF1006-102Y Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

SRF1006-102Y Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

SRF1006-102Y Features

  • 1mH inductance at 100kHz.
  • Rated for 50V DC operation.
  • Maximum current rating of 520mA.
  • Surface mountable SMD package.
  • Operating temperature range -40°C to 105°C.

SRF1006-102Y Applications

  • Effective EMI suppression.
  • Signal line filtering.
  • Maintaining signal integrity.
  • Suitable for various electronic circuits.

SRF1006-102Y FAQs

6 frequently asked questions generated from this part’s specifications.
What is the inductance of the SRF1006-102Y common mode choke?

The inductance is 1mH at 100kHz.

What is the maximum DC voltage rating for the SRF1006-102Y?

The maximum DC voltage rating is 50V.

What is the maximum current rating for this common mode choke?

The maximum current rating is 520mA.

What is the operating temperature range for the SRF1006-102Y?

The operating temperature range is -40°C to 105°C.

What type of package does the SRF1006-102Y use?

It uses a horizontal, 4-pad SMD package.

How is the SRF1006-102Y mounted?

It is designed for surface mounting.
