| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
220 pcs
|
220 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| AEC-Q200 | |
| Automotive Grade | |
| Core Material | |
| Current Rating | |
| Current Rating RMS (Nominal @ 100 kHz / 0.25 V) | |
| Current Saturation | |
| Current Saturation (Nominal @ 100 kHz / 0.25 V) | |
| DC Resistance (DCR) | |
| DC Resistance (Maximum @ 100 kHz / 0.25 V) | |
| HI-POT | |
| Halogen Free | |
| Height | |
| Inductance | |
| Inductance Drop | |
| Length | |
| Mounting Type | |
| Number of Coils | |
| Operating Temperature | |
| Ratings | |
| Shielding | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Rise | |
| Terminal Finish | |
| Tolerance | |
| Width | |
| Wire Material |
The Bourns SRF0703A-150M is a dual-winding shielded power inductor designed for applications requiring magnetic shielding and low radiation. It offers an inductance of 15µH with a tolerance of ±20% and a DC resistance of 119mΩ maximum.
This inductor features a current rating of 916mA and a saturation current of 2.05A. It operates within a temperature range of -40°C to 125°C and is AEC-Q200 compliant, making it suitable for demanding environments.
The SRF0703A-150M has a compact surface mount package measuring 7.60mm x 7.60mm with a height of 3.60mm. It is supplied on a reel with 1500 pieces.
Key electrical specifications include a typical temperature rise of 40°C at rated Irms and an inductance drop of 30% typical at Isat. The inductor is constructed with a ferrite core and enameled copper wire, featuring Sn terminal finish.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 15 µH with a tolerance of ±20% at 100 kHz / 0.25 V.
The maximum DC resistance is 119mΩ.
The current rating (Irms) is 916 mA, and the saturation current (Isat) is 2.05 A.
The operating temperature range is -40°C to 125°C.
Yes, the SRF0703A-150M is AEC-Q200 compliant.
The dimensions are 7.60mm in length, 7.60mm in width, and 3.60mm in height.
It is a surface mount component supplied on a reel with 1500 pieces.
