| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
819 pcs
|
819 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
| On Request | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Current Saturation | |
| DC Resistance (DCR) | |
| HI-POT | |
| Height | |
| Inductance | |
| Length | |
| Mounting Type | |
| Number of Coils | |
| Operating Temperature | |
| SVHC Present | |
| Shielding | |
| Storage Temperature | |
| Tolerance | |
| Width | |
| Wire |
The Bourns SRF0703-1R0M is a dual-winding shielded power inductor designed for various power supply applications. It offers an inductance value of 1µH with a tolerance of ±20% and a rated current of 2.63A (Irms), with a saturation current of 7.97A (Isat).
This inductor operates within a temperature range of -40°C to 125°C and features a magnetically shielded construction for low radiation. The component is housed in a Surface Mount package with dimensions of 7.60mm x 7.60mm x 3.60mm.
Key applications include SEPIC topologies and power supplies for communication equipment, notebooks, desktop computers, servers, LCDs, flat panels, backlights, camcorders, and HDTVs. The inductor utilizes a ferrite core and enameled copper wire, with an LCP base material.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance of the SRF0703-1R0M is 1 µH with a tolerance of ±20% at 100 KHz.
The current rating (Irms) for the SRF0703-1R0M is 2.63 A, with a saturation current (Isat) of 7.97 A.
The operating temperature range for the SRF0703-1R0M is -40°C to 125°C.
The SRF0703-1R0M is in a Surface Mount package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
