The Mean Well USA SPU01L-05 is an isolated DC-DC converter module designed for commercial ITE applications. It delivers a nominal 5V output at up to 200mA, providing 1W of isolated power from a 4.5V minimum input. The converter features a typical efficiency of 79% and includes short circuit protection (SCP) for reliable operation.
This module is housed in a 6-SIP (5 leads) through-hole package measuring 19.5mm x 6.1mm x 10.2mm, making it suitable for space-constrained board-level designs. The operating temperature range is -40°C to 90°C with derating, allowing use in a variety of environments.
Designed for commercial ITE equipment, the SPU01L-05 is a cost-effective solution for isolated power conversion where a single 5V output is required. Its through-hole mounting simplifies assembly and provides robust mechanical attachment.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.77 | $2.77 |
| 16+ | $2.34 | $2.34 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal output voltage is 5V.
The maximum output current is 200mA.
The power rating is 1W.
The operating temperature range is -40°C to 90°C with derating.
It comes in a 6-SIP module with 5 leads, through-hole mounting.
RoHS3 compliance is indicated but unverified.
It includes short circuit protection (SCP).
