SPLPL90-3 The Osram SPLPL90-3 is a laser diode featuring a power of 75W and a wavelength range of 895-915nm. It operates with a supply voltage of 8-11V DC and is designed for through-hole mounting.
Mfr Part #:

SPLPL90-3

Available from 1 distributors
Mfr Name: Osram
Osram
The Osram SPLPL90-3 is a laser diode featuring a power of 75W and a wavelength range of 895-915nm. It operates with a supply voltage of 8-11V DC and is designed for through-hole mounting.
✓ Total Stock: 1,000 pcs
$ Price Range: $8.12

SPLPL90-3 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

SPLPL90-3 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Industrial Grade
Medical Grade
Military Grade
Mounting Type
Operating Temperature
Power
Storage Temperature
Supply Voltage
Tape & Reel
Wavelength
View Similar Products (0)

SPLPL90-3 Description

Short technical summary and product information.

The ams OSRAM SPL PL90_3 is a laser diode designed for various applications requiring specific optical output. It operates within a wavelength range of 895 to 915nm, with a nominal wavelength of 905nm, and delivers a power output of 75W.



This component is suitable for systems requiring a supply voltage between 8 and 11V DC, with an operating current range of 0.5 to 1A. The diode has a diameter of 5mm and is housed in an infrared color package.



Designed for through-hole (THT) mounting, the SPL PL90_3 has an operating temperature range of -40°C to 85°C. It is packaged by the manufacturer in cardboard quantities of 50 pieces.

SPLPL90-3 Quick Information

Product Type: Laser Diode
Canonical Name: Osram SPL PL90_3 Laser Diode

SPLPL90-3 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SPLPL90-3 Estimated Pricing

Qty Low High
1+ $8.12 $8.12

Estimated market price range - modelled values for guidance only, not live distributor offers.

SPLPL90-3 Features

  • 75W laser diode power output.
  • 895-915nm wavelength range.
  • 8-11V DC supply voltage.
  • Through-hole mounting design.
  • -40 to 85°C operating temperature.

SPLPL90-3 Applications

  • Suitable for laser-based measurement systems.
  • Used in infrared laser communication devices.
  • Ideal for industrial laser material processing.
  • Applicable in scientific research involving infrared lasers.
  • Used in laser alignment and targeting applications.

SPLPL90-3 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the power output of the Osram SPLPL90-3 laser diode?

The Osram SPLPL90-3 laser diode has a power output of 75W.

What is the wavelength of the Osram SPLPL90-3 laser diode?

The wavelength of the Osram SPLPL90-3 laser diode is 895-915nm, with a nominal wavelength of 905nm.

What is the operating voltage for the Osram SPLPL90-3 laser diode?

The Osram SPLPL90-3 laser diode operates with a supply voltage of 8-11V DC.

What is the operating temperature range for the Osram SPLPL90-3 laser diode?

The Osram SPLPL90-3 laser diode operates within a temperature range of -40°C to 85°C.

How is the Osram SPLPL90-3 laser diode mounted?

The Osram SPLPL90-3 laser diode is designed for through-hole (THT) mounting.
