The NXP Semiconductors SPC5746CHK1ACMJ6 is a 32-bit dual-core microcontroller featuring 3MB of flash memory and 512KB of SRAM. It operates at clock speeds of 80MHz and 160MHz.

✓ Total Stock: 15,300 pcs

$ Price Range: $6.40

SPC5746CHK1ACMJ6 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Flip Electronics ✓ Non-Authorised Inventory information	15,300 pcs On Request	15300 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

SPC5746CHK1ACMJ6 Description

Short technical summary and product information.

This NXP Semiconductors SPC5746CHK1ACMJ6 microcontroller is built on the Power Architecture e200z2 and e200z4 cores, offering 32-bit processing with dual-core capabilities. It features 3MB of on-chip flash memory and 512KB of SRAM, supporting clock speeds of 80MHz and 160MHz. The device includes a comprehensive set of peripherals such as DMA, LVD, POR, WDT, CANbus, Ethernet, I2C, LINbus, SAI, SPI, and USB.

Designed for surface mounting, the SPC5746CHK1ACMJ6 comes in a 256-MAPPBGA (17x17) package. It operates within a voltage range of 3V to 5.5V and has an operating temperature range of -40°C to 85°C (TA). The microcontroller includes integrated analog-to-digital converters (80x10-bit, 64x12-bit) and various communication interfaces, making it suitable for complex embedded applications.
