| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Autonics SPA-100-12 is an enclosed AC/DC power supply converter designed for ITE (Commercial) applications. It provides a power output of 102W with a current rating of 8.5A.
Key electrical specifications include an efficiency of 72% and features such as adjustable output and universal input. The unit is designed for chassis mounting and offers a voltage isolation of 3 kV. Its operating temperature range is -10°C to 50°C with derating.
The dimensions of the converter are 160.0mm in length, 97.0mm in width, and 42.0mm in height. It complies with standard number 60950-1 and has received CE approval.
This converter is suitable for various commercial applications requiring a reliable and versatile power conversion solution.
The SPA-100-12 provides a single output of 12V at 8.5A.
The SPA-100-12 is rated for 102W of output power.
The operating temperature range is -10°C to 50°C with derating.
The efficiency is 72%.
The dimensions are 160.0mm (6.30") in length, 97.0mm (3.82") in width, and 42.0mm (1.65") in height.
The mounting type is chassis mount.
It is CE approved and complies with standard number 60950-1.
