| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Autonics SPA-075-24 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers 77W of power with a 24V DC output and a maximum output current of 3.2A.
The converter operates with a wide input voltage range of 85 to 264 VAC, accommodating universal power sources. It features adjustable output and universal input capabilities, enhancing its flexibility in various system designs. The unit is built for chassis mounting, providing a secure installation in industrial or commercial equipment.
With an efficiency rating of 78% and an isolation voltage of 3 kV, the SPA-075-24 meets standard safety requirements, including compliance with 60950-1. The operating temperature range is -10°C to 50°C with derating, suitable for a variety of environmental conditions. Its dimensions are 160.0mm x 97.0mm x 42.0mm.
This AC/DC converter is RoHS3 Compliant, has an MSL of 1 Unlimited, and is REACH Unaffected, indicating adherence to environmental regulations.
The output voltage is 24V.
The power rating is 77W.
The input voltage range is 85 to 264 VAC.
It supports chassis mounting.
The operating temperature range is -10°C to 50°C with derating.
Yes, it is RoHS3 Compliant.
