| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Autonics SPA-075-12 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers a 76W output power with a single 12V output voltage and a current rating of 6.3A.
This converter features adjustable output and universal input, supporting a wide input voltage range of 85 to 264 VAC. Its dimensions are 160.0mm x 97.0mm x 42.0mm, making it suitable for chassis mounting. The unit is CE approved and operates within a temperature range of -10°C to 50°C with derating.
Key specifications include 3 kV isolation voltage and 78% efficiency. The SPA-075-12 is built to meet standard 60950-1.
This product is part of the Autonics SPA series, offering reliable power conversion solutions for various electronic systems.
The output voltage is 12V.
The output current is 6.3 A.
The power rating is 76W.
The operating temperature range is -10°C to 50°C with derating.
The input voltage range is 85 ~ 132 VAC and 170 ~ 264 VAC.
The dimensions are 160.0mm L x 97.0mm W x 42.0mm H.
The RoHS status is RoHS3 Compliant.
