| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage |
The Autonics SPA-075-05 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers a 75W output power with a 5V output voltage and a maximum output current of 15A. This converter features universal input voltage compatibility, accepting a wide range from 85 to 264 VAC.
Designed for versatility, the SPA-075-05 includes adjustable output and universal input features. Its dimensions are 160.0mm in length, 97.0mm in width, and 42.0mm in height, making it suitable for chassis mounting. The operating temperature range is -10°C to 50°C with derating. It meets the Standard Number 60950-1 and provides 3 kV of isolation voltage.
Compliance information indicates RoHS3 Compliant status, Moisture Sensitivity Level 1 Unlimited, and REACH Unaffected. The efficiency rating is 70%.
85-132 VAC and 170-264 VAC (selectable ranges).
-10°C to 50°C with derating.
Chassis mount.
5V at 15A, 75W.
Yes, adjustable output.
3 kV.
70%.
