The Autonics SPA-030-12 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a power output of 30W with a 12V rating.
Key electrical specifications include a current rating of 2.5A and an efficiency of 74%. This model offers features such as adjustable output and universal input, making it versatile for various power supply needs. The unit is designed for chassis mounting and has a voltage rating of 3 kV.
Operating within a temperature range of -10°C to 40°C (with derating), the SPA-030-12 meets standard number 60950-1. Its dimensions are 120.0mm in length, 97.0mm in width, and 40.0mm in height.
This converter complies with RoHS3 standards and has an MSL rating of 1. It is suitable for applications requiring a reliable and efficient AC to DC power conversion.
-10°C to 40°C (with derating).
3 kV.
30W.
2.5 A.
74%.
CE certified to standard 60950-1.
1 output.
Enclosed chassis mount, 120mm x 97mm x 40mm.
