| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Tape & Reel | |
| Type | |
| Voltage |
The Kaga Electronics USA SP15U-48S is an enclosed AC/DC converter with a power rating of 15W. It is designed for chassis mounting and suitable for ITE (Commercial) applications.
This converter accepts a wide input voltage range of 85 to 264 VAC, making it versatile for various power environments. It provides three output voltages: 5VDC, +15VDC, and -15VDC, with corresponding current capabilities of 2A, 450mA, and 450mA respectively. The isolation voltage is rated at 3 kV.
Key features include adjustable output, DC input capability, and universal input. The operating temperature range is from 0°C to 60°C with derating. The dimensions are 107.0mm x 75.0mm x 33.0mm.
Compliance agencies include CE, cUL, TUV, and UL. The RoHS status is RoHS3 Compliant, MSL is 1 Unlimited, and REACH status is Unaffected.
The SP15U-48S provides three output voltages: 5VDC, +15VDC, and -15VDC.
The input voltage range is 85 to 264 VAC.
The power rating is 15W.
The operating temperature range is 0°C to 60°C with derating.
The dimensions are 107.0mm x 75.0mm x 33.0mm.
Approval agencies include CE, cUL, TUV, and UL.
