| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Frequency | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage |
This AC/DC converter from Kaga Electronics USA, part number SP15U-0522T, delivers 15W of power with multiple output voltages: 5V, +15V, and -15V. It is designed for universal input, accepting AC voltages from 85 to 264V at frequencies of 47-63 Hz. The unit offers a typical efficiency of 73% and features built-in over-voltage and over-current protection on the 5V output.
With a chassis mount type and an enclosed form factor, this converter is suitable for ITE (Commercial) applications. It operates within a temperature range of 0°C to 60°C, with derating applied above 50°C. Key electrical specifications include isolation voltage ratings of 3000VAC (primary to secondary), 1500VAC (primary to case), and 500VAC (secondary to case), along with a minimum isolation resistance of 100 Mohms.
The physical dimensions are 107.0mm x 75.0mm x 33.0mm. The series is SP15U-T, and it carries approvals from CE, cUL, TUV, and UL.
The SP15U-0522T has three outputs: 5V, +15V, and -15V.
The power rating is 15W.
The input voltage range is 85-264 VAC.
The operating temperature range is 0°C to 60°C, with derating after 50°C.
It uses chassis mount.
Approval agencies include CE, cUL, TUV, and UL.
