| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,162 pcs
|
3162 pcs | On Request | 1 | On Request | On Request | 19+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Capacitance @ Frequency | |
| Current | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| Power Line Protection | |
| Supplier Device Package | |
| Supplier Package | |
| Type | |
| Unidirectional Channels | |
| Voltage |
The Littelfuse Inc. SP1224-01UTG is a unidirectional TVS Diode with a Zener type classification, suitable for general purpose applications. It is designed to handle a peak pulse power of 3700W (3.7kW) and can withstand a peak pulse current of 100A at an 8/20µs waveform.
This device operates within a temperature range of -40°C to 125°C (TA). Its electrical characteristics include a typical voltage of 37V and a capacitance of 770pF at 1MHz. It features a single unidirectional channel for protection.
The SP1224-01UTG is supplied in a 6-UFDFN exposed pad package, measuring 1.8x2mm, and is designed for surface mount applications. It is RoHS3 compliant and has an MSL rating of 1, indicating unlimited shelf life under standard conditions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.55 | $0.55 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical clamping voltage is 37V.
The peak pulse current is 100A under an 8/20µs waveform.
It comes in a 6-UFDFN exposed pad package (6-µDFN 1.8x2mm) for surface mounting.
-40°C to 125°C.
3700W (3.7kW).
It has one unidirectional channel.
