SP-75-5 The Mean Well USA SP-75-5 is a 75W AC/DC converter featuring a chassis mount and enclosed type. It offers adjustable output, PFC, and universal input.
Mfr Part #:

SP-75-5

Mfr Name: Mean Well USA
Mean Well USA
The Mean Well USA SP-75-5 is a 75W AC/DC converter featuring a chassis mount and enclosed type. It offers adjustable output, PFC, and universal input.
Stock on Request

SP-75-5 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Features
Height
Length
Mounting Type
Number of Outputs
Operating Temperature
Power (Watts)
Type
Voltage
Width
View Similar Products (0)

SP-75-5 Description

Short technical summary and product information.

The Mean Well USA SP-75-5 is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a power output of 75W with a single output channel and a current rating of 15A.



Key electrical specifications include an efficiency of 76%, adjustable output, Power Factor Correction (PFC), and universal input capabilities. The unit is designed for chassis mounting and operates within a temperature range of -10°C to 70°C, with derating applied.



This converter meets various approval agency standards, including CB, CE, cURus, and TUV. Its dimensions are 179.0mm in length, 97.0mm in width, and 33.0mm in height.

SP-75-5 Quick Information

Product Type: AC/DC Converter
Series: SP-75
Canonical Name: Mean Well USA SP-75-5 AC/DC Converter
Subcategory: Enclosed

SP-75-5 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

SP-75-5 Features

  • 75W enclosed AC/DC converter.
  • Chassis mountable for easy integration.
  • Features adjustable output and PFC.
  • Universal input voltage range.
  • Rated for ITE (Commercial) applications.

SP-75-5 Applications

  • Power for ITE (Commercial) equipment
  • 75W enclosed chassis mount supply
  • Single output 5V 15A power
  • Industrial control panel power source
  • Adjustable output with PFC feature

SP-75-5 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating temperature range of the SP-75-5?

-10°C to 70°C with derating.

What is the efficiency of the SP-75-5?

76%.

What are the dimensions of the SP-75-5?

179.0mm x 97.0mm x 33.0mm (7.05" x 3.82" x 1.30").

What safety approvals does the SP-75-5 have?

CB, CE, cURus, TUV.

What is the mounting type of the SP-75-5?

Chassis mount.

How many outputs does the SP-75-5 have?

1 output.

What features does the SP-75-5 include?

Adjustable output, power factor correction (PFC), and universal input.
