| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage |
The Mean Well USA SP-100-5 is an enclosed AC/DC converter with a power rating of 100W and an output voltage of 5V. It is designed for chassis mounting and offers features such as adjustable output, power factor correction (PFC), remote on/off control, and universal input.
This converter operates within a temperature range of -10°C to 60°C with derating. It has a single output and is approved by CB, CE, cURus, and TUV, making it suitable for ITE (Commercial) applications. The dimensions are 179.0mm in length, 99.0mm in width, and 45.0mm in height.
Key electrical specifications include an efficiency of 79% and a current rating of 20A. The voltage rating is 3 kV. The RoHS status is RoHS3 Compliant, Moisture Sensitivity Level (MSL) is 1 Unlimited, and REACH status is REACH Unaffected. The DK Part Number is SP-100-5-ND.
The SP-100-5 has a power output of 100W.
The SP-100-5 uses chassis mount.
The operating temperature range for the SP-100-5 is -10°C to 60°C (With Derating).
Key features include Adjustable Output, PFC, Remote On/Off, and Universal Input.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
The REACH status is REACH Unaffected.
