| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Dimensions | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Overload Protection | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Weight | |
| Width |
The Mean Well USA SP-100-15 is an enclosed AC DC power supply designed for ITE (Commercial) applications. It provides a stable 15V output at a rated current of 6.7A, delivering up to 101W of power.
This converter operates with a universal AC input range of 85-264VAC and features a power factor greater than 0.93 at full load. Key electrical specifications include a typical efficiency of 84% and protections against short circuit, overload, and over voltage. It also includes a built-in constant current limiting circuit and supports remote ON/OFF control as an option.
The unit is chassis mounted and has dimensions of 179mm x 99mm x 45mm. It operates within a temperature range of -10°C to 60°C with derating and meets various safety standards including UL60950-1 and EN61558-1, along with EMC standards like EN55032 Class B.
The SP-100-15 has a nominal output voltage of 15V.
The rated current for the SP-100-15 is 6.7A.
The SP-100-15 has a power rating of 101W.
The typical efficiency of the SP-100-15 at full load is 84%.
The SP-100-15 accepts a universal AC input voltage range of 85-264VAC.
The SP-100-15 operates within a temperature range of -10°C to 60°C, with derating applied.
The SP-100-15 complies with UL60950-1, TUV EN60950-1, EN61558-1, EN61558-2-16, and CCC GB4943.
