The Cosel SNDBS700B48 is a high-power DC-DC converter designed for ITE (Commercial) applications. This open frame unit offers a robust 48V output voltage with a maximum current of 14.5A, delivering up to 696W of power.
Key electrical specifications include an input voltage range of 200-400 VDC and a high efficiency of 91% typical. The converter is built with overcurrent, overvoltage, and thermal protection circuits, along with remote ON/OFF control and remote sensing capabilities for enhanced system management.
Mechanically, the SNDBS700B48 features a chassis mount design with dimensions of 222.3mm x 89.2mm x 44.5mm. It operates within an ambient temperature range of -20°C to 95°C with derating. Safety agency approvals include CE and cURus, ensuring compliance with international standards.
This series includes built-in features like inverter operating monitoring (IOG) and parallel operation capabilities, making it a versatile solution for demanding power conversion needs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 48V.
The maximum output power is 696W.
The input voltage range is 200-400 VDC.
The typical efficiency is 91%.
The operating temperature range is -20°C to 95°C with derating.
Yes, it works over 105% of rating and recovers automatically.
It uses chassis mount.
