| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
71,042 pcs
|
71042 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request | |
|
3,250 pcs
|
3250 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2,484 pcs
|
2484 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request | |
|
779 pcs
|
779 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
117 pcs
|
117 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Data Rate | |
| Duplex | |
| Fault Protection | |
| Lead Spacing | |
| Mounting Type | |
| Number of Drivers | |
| Operating Temperature | |
| Protocol | |
| Receiver Hysteresis | |
| Supplier Device Package | |
| Supplier Package | |
| Supply Current | |
| Type | |
| Voltage |
The SN65HVD75DR from Texas Instruments is a 3.3-volt half-duplex transceiver supporting RS-485 and RS-422 protocols. It is engineered for reliable serial communication, offering a maximum signaling rate of 20 Mbps.
Key electrical characteristics include a wide common-mode voltage range of -7V to 12V and fault protection from -13V to 16.5V. The device boasts ±12kV IEC ESD protection on the bus pins, enhancing its durability in harsh environments. It operates over an extended industrial temperature range of -40°C to 125°C.
Designed for ease of integration, the SN65HVD75DR supports up to 200 connected nodes on a single bus, thanks to its low unit loading. It features 5V tolerant logic inputs, making it compatible with both 3.3V and 5V controllers. The transceiver is available in an 8-SOIC package, suitable for surface mount applications.
This transceiver is optimized for applications requiring robust and efficient serial data transmission, such as industrial automation, building control systems, and point-of-sale equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.81 | $0.81 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The SN65HVD75DR operates at 3.3V.
The SN65HVD75DR is available in an 8-SOIC package.
The SN65HVD75DR operates from -40°C to 125°C.
The SN65HVD75DR is RoHS3 Compliant.
The SN65HVD75DR has a maximum signaling rate of 20 Mbps.
The SN65HVD75DR offers ±12kV IEC ESD protection on the bus pins.
The SN65HVD75DR allows over 200 connected nodes.
